Sunsynk Battery

Power your home or business with the Sunsynk SUN-BATT series – a premium range of LiFePO₄ (Lithium Iron Phosphate) batteries designed for solar energy storage, backup power, and off-grid systems. With capacities from 5.12kWh to 15.97kWh, and scalable up to 127.76kWh, Sunsynk batteries offer unmatched flexibility, safety, and performance.

Key Features:

• 100% Depth of Discharge (DoD) – Maximize usable energy.
• 6000+ Cycle Life – Long-lasting reliability.
• Scalable Design – Connect up to 8 or 32 units in parallel (model-dependent).
• Certified Safe – UN38.3, IEC62619, UL1642, CE, UKCA.
• Flexible Installation – Wall-mounted or floor-standing.
• Smart Communication – RS232, RS485, CAN, and Wi-Fi (select models).
• Quick Setup – One-button ON/OFF, automatic ID assignment.
• IP Ratings – IP20 to IP65 for indoor and semi-outdoor environments.

Model Specifications:

SUN-BATT-5.12 (IP65)

• Energy: 5.12kWh
• IP Rating: IP65
• Installation: Wall-mounted
• (Detailed specs pending – contact for full datasheet)

SUN-BATT-5.32

• Energy: 5.32kWh (104Ah)
• Voltage: 51.2V
• Max Power: 5kW
• Weight: 45kg
• Size: 450×150×533mm

SUN-BATT-10.24

• Energy: 10.24kWh (200Ah)
• Usable Energy: 9.21kWh
• Voltage: 51.2V
• Max Power: 12kW
• Weight: 101kg
• Size: 610×760×200mm
• IP Rating: IP65
• Scalability: Up to 32 units (327kWh)

SUN-BATT-10.65

• Energy: 10.65kWh (208Ah)
• Voltage: 51.2V
• Max Power: 10kW
• Weight: 90kg
• Size: 550×160×836mm

SUN-BATT-15.97

• Energy: 15.97kWh (312Ah)
• Voltage: 51.2V
• Max Power: 15kW
• Weight: 140kg
• Size: 720×160×916mm

Certifications:

• Battery Pack: UN38.3, IEC62619, IEC61000, CE, UKCA
• Battery Cell: UN38.3, UL1642, JET

Applications:

• Solar energy storage
• Backup power systems
• Off-grid living
• Commercial energy solutions
