Shoto 5.12kWh Box5 Pro

The Shoto Box 5 Pro is a high-performance, modular lithium battery system designed for residential and commercial energy storage. With a 5.12kWh nominal capacity, it offers reliable power for grid-tied, off-grid, and solar applications.

Key Features:

• Industrial Design: Sleek, minimalist aesthetic with flexible installation options—stackable, wall-mounted, or vertical. Available in gray or white.
• Expandable Capacity: Modular 100Ah LFP prismatic cells allow expansion up to 102kWh with up to 20 units in parallel.
• Long Lifespan: Over 6000 cycles at 80% depth of discharge (DOD), with a 15-year design life.
• Smart Monitoring: Real-time battery status via Bluetooth and mobile app.
• Broad Compatibility: Supports 20+ inverter brands including Growatt, Victron, SMA, Sungrow, and more.
• Certified Safety: Complies with UL1973, IEC62619, CE-EMC, UN38.3, and other international standards.
• Optional Add-ons: Anti-theft protection, fire safety features, and LCD display modules.

Technical Specifications:

• Nominal Voltage: 51.2V
• Voltage Range: 45.0V – 56.4V
• Nominal Energy: 5.12kWh
• Available Energy: 4.86kWh
• Max Output Power: 5kW (Peak: 5.4kW for 10s)
• Max Charging Current: 50A
• Max Discharge Current: 100A
• Efficiency: ≥97%
• Dimensions: 580 × 250 × 440 mm
• Weight: 46kg
• Cooling: Natural convection
• Operating Temperature: -20°C to 50°C

Applications:

Ideal for home energy storage, solar PV systems, backup power, and sustainable energy solutions.

Shoto 5.12kW Pro Box 5 Specifications Document
