Deye Grid Tied Inverter—
$2,809.55
The Story
Power large-scale solar projects with Deye’s advanced grid-tied inverter technology. Designed for commercial and industrial applications, these inverters deliver exceptional efficiency, robust safety features, and intelligent monitoring for maximum energy yield.
Key Features
- Models Available: 60kW and 110kW three-phase string inverters.
- High Efficiency: Up to 98.8% conversion efficiency with MPPT efficiency >99%.
-
Multiple MPPT Trackers:
- 60kW model: 8 MPPT trackers for optimized energy harvest.
- 110kW model: 6 MPPT trackers for large-scale PV arrays.
- Wide Voltage Range: Supports 200–850V MPPT operating range for flexible system design.
- Smart Monitoring: Optional string-level monitoring and remote parameter control.
- Zero Export & VSG Applications: Ideal for grid compliance and advanced energy management.
- Anti-PID Function: Optional protection against potential-induced degradation.
Technical Highlights
-
60kW Model (SUN-60K-G01P3-EU-AM8-LV):
- Max PV Input Power: 80kW
- Rated AC Output: 60kW
- Dimensions: 1006×516×325.5 mm | Weight: 103 kg
- IP65 protection | Intelligent air cooling
-
110kW Model (SUN-110K-G03):
- Max DC Input Power: 150kW
- Rated AC Output: 110kW
- Dimensions: 838×568×326 mm | Weight: 81 kg
- IP65 protection | Smart cooling system
Safety & Standards
- Comprehensive protection: Overvoltage, short circuit, ground fault, anti-islanding, surge protection (Type II DC/AC).
- Certified to IEC 61727, IEC 62116, EN 50549, VDE-AR-N 4105, AS4777.2, and more.
- Built for harsh environments: Operating temperature -25°C to +60°C, altitude up to 4000m.
Why Choose Deye?
- Maximum Yield: High efficiency and multiple MPPT trackers for optimal performance.
- Scalable & Reliable: Perfect for large commercial and utility-scale solar installations.
- Warranty: 5 years standard.
