The Story
The 615W Canadian Solar Panel is a high-performance, utility-scale photovoltaic module designed for maximum energy output, long-term reliability, and lower levelized cost of energy. Built with N-type TOPCon bifacial cell technology, this module delivers superior efficiency, reduced degradation, and enhanced performance in hot and demanding environments.
Engineered by Canadian Solar (CSI Solar Co., Ltd.), a global leader in solar manufacturing with over 150 GW of modules delivered worldwide, the 615W panel is ideally suited for commercial, industrial, and large-scale solar installations.
Key Product Benefits
- High Power Output: 615 watts nominal power for increased energy density per module
- Advanced N-Type TOPCon Cells: Higher efficiency, improved temperature performance, and long-term stability
- Bifacial Design: Up to 85 percent rear-side power bifaciality for additional energy yield when mounted on reflective surfaces
- Excellent Hot Climate Performance: Low temperature coefficient of −0.29 percent per degree Celsius ensures stable output in high temperatures
- Low Degradation: First-year degradation ≤ 1 percent, then ≤ 0.4 percent annually
- Strong Mechanical Durability: Tested for heavy snow loads up to 5400 Pa and wind loads up to 2400 Pa
- Higher System Value: Designed to reduce balance-of-system costs and improve overall project economics
Electrical Specifications (STC – 615W Model)
- Nominal Max Power (Pmax): 615 W
- Module Efficiency: 22.8 percent
- Operating Voltage (Vmp): 41.0 V
- Operating Current (Imp): 15.01 A
- Open Circuit Voltage (Voc): 48.2 V
- Short Circuit Current (Isc): 16.02 A
- Maximum System Voltage: 1500 V (IEC / UL)
Mechanical Specifications
- Cell Technology: N-type TOPCon bifacial cells
- Cell Configuration: 132 half-cells
- Module Dimensions: 2382 x 1134 x 30 mm
- Weight: 32.8 kg
- Front Glass: 2.0 mm heat-strengthened glass with anti-reflective coating
- Back Glass: 2.0 mm heat-strengthened glass
- Frame: Anodized aluminum alloy
- Junction Box: IP68 rated with 3 bypass diodes
- Connector Type: MC4-EVO2A or T6
- Operating Temperature Range: −40°C to +85°C
Reliability and Quality Standards
- Certified to IEC 61215 and IEC 61730
- Fire Safety Rating: UL 61730 Type 29 / IEC Class C
- Manufacturing Certifications:
- ISO 9001 (Quality Management)
- ISO 14001 (Environmental Management)
- ISO 45001 (Occupational Health and Safety)
- Resistance to PID and LeTID for long-term performance stability
Warranty
- Product Warranty: 12-year enhanced warranty on materials and workmanship
-
Performance Warranty: 30-year linear power output warranty
- Year 1 degradation: ≤ 1 percent
- Annual degradation thereafter: ≤ 0.4 percent
Ideal Applications
- Utility-scale solar power plants
- Commercial and industrial rooftop installations
- Ground-mounted and tracker-based solar systems
- Projects requiring high energy yield per square meter
Description
The 615W Canadian Solar Panel is a high-performance, utility-scale photovoltaic module designed for maximum energy output, long-term reliability, and lower levelized cost of energy. Built with N-type TOPCon bifacial cell technology, this module delivers superior efficiency, reduced degradation, and enhanced performance in hot and demanding environments.
Engineered by Canadian Solar (CSI Solar Co., Ltd.), a global leader in solar manufacturing with over 150 GW of modules delivered worldwide, the 615W panel is ideally suited for commercial, industrial, and large-scale solar installations.
Key Product Benefits
- High Power Output: 615 watts nominal power for increased energy density per module
- Advanced N-Type TOPCon Cells: Higher efficiency, improved temperature performance, and long-term stability
- Bifacial Design: Up to 85 percent rear-side power bifaciality for additional energy yield when mounted on reflective surfaces
- Excellent Hot Climate Performance: Low temperature coefficient of −0.29 percent per degree Celsius ensures stable output in high temperatures
- Low Degradation: First-year degradation ≤ 1 percent, then ≤ 0.4 percent annually
- Strong Mechanical Durability: Tested for heavy snow loads up to 5400 Pa and wind loads up to 2400 Pa
- Higher System Value: Designed to reduce balance-of-system costs and improve overall project economics
Electrical Specifications (STC – 615W Model)
- Nominal Max Power (Pmax): 615 W
- Module Efficiency: 22.8 percent
- Operating Voltage (Vmp): 41.0 V
- Operating Current (Imp): 15.01 A
- Open Circuit Voltage (Voc): 48.2 V
- Short Circuit Current (Isc): 16.02 A
- Maximum System Voltage: 1500 V (IEC / UL)
Mechanical Specifications
- Cell Technology: N-type TOPCon bifacial cells
- Cell Configuration: 132 half-cells
- Module Dimensions: 2382 x 1134 x 30 mm
- Weight: 32.8 kg
- Front Glass: 2.0 mm heat-strengthened glass with anti-reflective coating
- Back Glass: 2.0 mm heat-strengthened glass
- Frame: Anodized aluminum alloy
- Junction Box: IP68 rated with 3 bypass diodes
- Connector Type: MC4-EVO2A or T6
- Operating Temperature Range: −40°C to +85°C
Reliability and Quality Standards
- Certified to IEC 61215 and IEC 61730
- Fire Safety Rating: UL 61730 Type 29 / IEC Class C
- Manufacturing Certifications:
- ISO 9001 (Quality Management)
- ISO 14001 (Environmental Management)
- ISO 45001 (Occupational Health and Safety)
- Resistance to PID and LeTID for long-term performance stability
Warranty
- Product Warranty: 12-year enhanced warranty on materials and workmanship
-
Performance Warranty: 30-year linear power output warranty
- Year 1 degradation: ≤ 1 percent
- Annual degradation thereafter: ≤ 0.4 percent
Ideal Applications
- Utility-scale solar power plants
- Commercial and industrial rooftop installations
- Ground-mounted and tracker-based solar systems
- Projects requiring high energy yield per square meter
